Appendix B Need More Slots?
41
Combination Configurations
Depending on your business requirements, and your physical space
limitations, you can add additional Expansion System in multiple
configurations, such as these. These combinations are only limited by
the available slot types: PCIe or PCI.
W o rk sta tio n
F a n -O u t D a is y -C h a in C o m b in a tio n C o n fig u ra tio n
W o rk sta tio n
D a is y -C h a in F a n -O u t C o m b in a tio n C o n fig u ra tio n
Obviously, you will need to keep an eye on your system performance
and make any adjustments that may be required, either to PCI card
location or to Expansion System configuration, to obtain maximum
performance.
