OM-1600 Page 3
SECTION 2 − SPECIFICATIONS
2-1. Specifications
Model
DB17 DB17V (With Gas Valve)
Ampere Rating 150 Amps W/Argon Gas @ 100% Duty Cycle DCEN, ACHF
Cooling Method Air
Tungsten Size .020 Thru 1/8 in (0.5 Thru 3.3 mm)
Cable Options 12-1/2 ft (3.8 m) or 25 ft (7.6 m) One-Piece High−Flex 12-1/2 ft (3.8 m) Or 25 ft (7.6 m) One-Piece High−Flex, Or
12-1/2 ft (3.8 m) Or 25 ft (7.6 m) Two-Piece High−Flex
Dimensions Length: 8 in (203 mm); Handle Diameter: 15/16 in (24 mm);
Weight: 3.7 oz (105 g) Length: 8 in (203 mm); Handle Diameter: 15/16 in (24 mm);
Weight: 4.5 oz (138 g)
2-2. Duty Cycle
Continuous Welding
sb1.5* 8/93
100% Duty Cycle At 150 Amperes Using Argon Gas
Duty Cycle is percentage of 10
minutes that torch can weld at
rated load without overheating.
0
10
Minutes
Definition
EXCEEDING RATED AMPERAGE can damage torch and void warranty.
•
Do not exceed rated amperage (see Section 2-1)
