Appendix C: Technical Information
Specifi cations
Main Mix Noise
(20 Hz–20 kHz bandwidth, 1/4" Main out, channel gains @
unity gain, channel EQs fl at, all channels assigned to Main Mix,
odd channels panned left, even channels panned right.)
Main Mix fader unity, channel faders down: –88.5 dBu
(92 dB Signal to Noise Ratio, ref +4 dBu)
Main Mix fader unity, channel faders @ unity: –82.5 dBu
Total Harmonic Distortion (THD)
(1 kHz 35 dB gain, 20 Hz–20 kHz bandwidth)
Mic in to insert send: <0.0007%
Mic in to Main Out: <0.005%
Attenuation (Crosstalk)
(1 kHz relative to 0 dBu, 20 Hz–20 kHz bandwidth,
Line in, 1⁄4" Main Out, Gain @ unity.)
Channel Mute switch engaged: –84 dBu
Channel Gain knob down: –84 dBu
Frequency Response
(Mic input to any output.)
20 Hz to 60 kHz: +0 dB/–1 dB
20 Hz to 100 kHz: +0 dB/–3 dB
Equivalent Input Noise (EIN)
(Mic in to Insert Send out, max gain.)
150 ohm termination: –129.5 dBu
Common Mode Rejection Ratio (CMRR)
(Mic in to Insert Send out, max gain.)
1 kHz: better than –70 dB
Maximum Levels
Mic in: +22 dBu
All other inputs: +22 dBu
Main Mix TRS out: +28 dBu
All other outputs: +22 dBu
Impedances
Mic in: 2.5 kilohms
Channel Insert return: 2.5 kilohms
All other inputs: 10 kilohms or greater
Tape out: 1.1 kilohms
All other outputs: 120 ohms
EQ
High Shelving ±15 dB @ 12 kHz
Mid Peaking ±15 dB sweep 100 Hz–8 kHz
Low Shelving ±15 dB @ 80 Hz
Low Cut Filter 18 dB/octave, –3 dB @ 75 Hz
Power Consumption
50 watts
Fuse Ratings
100–120 VAC 1A Slo Blo, 5 x 20 mm
220–240 VAC 0.5A Slo Blo, 5 x 20 mm
Dimensions (H x W x D) in Normal Pod Position
17.5" x 17.3" x 5.1" (445 mm x 440 mm x 129 mm)
Weight
20.0 lb (9.1 kg)
LOUD Technologies Inc. is always striving to improve our prod-
ucts by incorporating new and improved materials, components,
and manufacturing methods. Therefore, we reserve the right to
change these specifi cations at any time without notice.
