DiskOnChip 9x12 BGA-to-32-Pin DIP Adapter
93-SR-002-26-6L 5
2.3 Inserting DiskOnChip into the Adapter
To insert a DiskOnChip 9x12 BGA device into the adapter:
1. Identify the alignment ball (A) of DiskOnChip, at location C1 in the ball diagram. Refer to the
relevant data sheet for more information on the ball diagram.
2. Place DiskOnChip in the socket so that the alignment ball faces the white line on the PCB. See
Figure 1 for the location of the white alignment line.
3 Ordering Information
3.1 DiskOnChip
Ordering information for DiskOnChip devices supported by the BGA-to-32-pin DIP adapter is listed
in Table 2.
Table 2: Ordering Information for Supported DiskOnChip Devices
Device Capacity Product Number
16MB MD3831-D16-V3Q18-T
32MB MD3831-D32-V3-T
DiskOnChip Millennium Plus
64MB MD3331-D64-V3-T
16MB MD3831-D16-V3Q18-T
32MB MD3331-D32-V3Q18-T
Mobile DiskOnChip Plus
64MB MD3331-D64-V3-T
3.2 DiskOnChip Accessories
Ordering information for DiskOnChip accessories that can be used with the BGA-to-32-pin DIP
adapter is listed in Table 3.
Table 3: Ordering Information for Compatible DiskOnChip Accessories
Accessory Product Number
ISA Bus EVB for 3V DIP DIP-ISA-V3-EVB
ISA Bus EVB for 5V DIP DIP-ISA-V5-EVB
PCI EVB PCI-EVB-V1
GANG Programmer, Revision C DOC-DIP-GANG
