95-8150 KIT ASSEMBLY
2
Assemble the climate controls and
Double DIN or stacked ISO mount
units into the factory brackets using
the hardware from disassembly and
the screws supplied with the Double
DIN or stacked ISO mount units.
(Figure A)
1
Before tightening the top (2) mounting
screws to the Double DIN or stacked
ISO mount units attach the Double
DIN trim plate and secure with the top
(2) mounting screws. (Figure B)
2
Continue to final assembly.
A
B
LEXUS ES SERIES 1992-1996
DOUBLE DIN RADIO
STACKED ISO MOUNT UNITS PROVISON
Note: Refer also to the instructions included with the aftermarket radio.
