Nº33h monaural power amplifier – Mark Levinson No. 33H User Manual
Page 6
Nº33H Monaural Power Amplifier
Rated power output:
150W/ch continuous rms power @ 8
Ω
300W/ch continuous rms power @ 4
Ω
The above power ratings measured as continuous (rms) power
from 20Hz–20kHz with no more than 0.3% THD (assuming that the AC mains can
deliver adequate current, without its own voltage sagging)
Frequency response:
within 0.2dB from 20Hz to 20kHz
Signal-to-noise ratio
(main outputs):
better than –80dB (ref. 1W)
Voltage gain:
26.8dB
Input impedance:
100k
Ω (balanced)
50k
Ω (single-ended)
Input sensitivity:
1.59V for full rated output
Output impedance:
less than 0.05
Ω from 20Hz–20kHz
Power consumption:
typically 540 watts (±5%) at idle
typically 210 watts (±5%) in standby
Mains voltage:
100V, 120V, 220V, 230V, or 240V at either 50 or 60Hz, factory set for destination country
Connector complement:
(2) pairs custom binding posts
(1) balanced input on XLR
(1) single-ended input on Mark Levinson RCA
(1) 3.5mm trigger out jack
(1) 3.5mm trigger in jack
(1) RJ-45 communications port (Mark Levinson Linking
™
)
(1) RJ-11 communications port (Mark Levinson Linking
™
)
(1) captive high current AC mains cord
Overall dimensions:
width:
11"
(27.94cm)
height: 18.5"
(47cm)
depth:
22.875" (58.1cm)
Shipping weight:
220lb (100kg) each
Specifications are subject to change without notice.
