41
ENGLISH
SECTION 6
PARTS LIST
SINGLE OVEN EXPLODED VIEW
ITEM
Q
T
Y
PART NO.
DESCRIPTION
1
1
48382
UPPER LH END PLUG ASSEMBLY
(INCLUDES ITEM 5 EYEBROW)
2
1
48387
LOWER LH END PLUG ASSEMBLY
3
1
48408
L
O
WER RH END PLUG ASSEMBLY
4
1
48412
UPPER RH END PLUG ASSEMBLY
(INCLUDES ITEM 6 EYEBROW)
5
1
48378
EYEBROW, UPPER LH END PLUG ASSEMBLY
6
1
48410
EYEBROW, UPPER RH END PLUG ASSEMBLY
7
4
51398
END PLUG MOUNTING BRACKET ASSEMBLY .875
8
8
21296-0005
SCREW, HEX HEAD, WSHHD 12-14X3/4 SS BSD
9
6
36452
NUT, WING-PLASTIC 1/4-20
1
0
4
3101908
LEG, 4” ADJ FT (NPS)
1
1
1
48395
BOTTOM TRAY ASSEMBLY
1
2
1
48396
COVER, TOP
1
3
4
51387
SCR, MS, SLT TRHD 8-32X1/2 18-8
1
4
1
M10434
CORDSET, 50 AMP 250V 2P 3W
(208/240 V MODELS ONLY)
1
5
1
45739
NAMEPLATE, MM
1
6
1
47862
ASSY, COVER, MOTOR
