The Data/Fax Modem
The system automatically sets up the integrated analog modem. To use the modem func-
tions, connect the modem socket to an analog telephone socket (not ISDN) using the
telephone cable.
Proper use:
The modem can be connected to all analog sockets in Europe.
It is to be used solely for data communication purposes.
Do not attempt to
connect the modem
to an ISDN telephone
socket! This would re-
sult in serious damage
to the device.
The LAN Port
The built-in network adapter enables your computer to connect to the Internet via a
10/100/1000 Mbps network or DSL.
The connection is made via an Ethernet network cable and RJ-45 connectors. These are
inserted on the back of the computer and into an available network hub or DSL socket.
Under no circumstanc-
es should you con-
fuse a network cable
RJ-45 connector with
an ISDN connector!
NEVER attempt to con-
nect the LAN adapter
to an ISDN telephone
socket!
This would result in
serious damage to the
device.
