6
99-2005 KIT ASSEMBLY
CADILLAC DEVILLE 2000-2005
NOTE: In order to DIN mount in the 2000-2004 Deville you will need to use the provided
spacer as described below. There is not enough depth to ISO mount or DIN mount without
the spacer.
S-E
S-E
D
D
D
D
98-04
S
98-04
S
98-04
S
A
B
C
Remove all tabs except the ones marked
D from the radio housing. (Figure A)
When installing the 99-2005 housing into
the sub dash, use the supplied (4) phillips
screws and mount in the locations shown
(Figure C)
1
3
When DIN mounting slide the included
spacer onto the DIN cage that came with
your aftermarket radio before inserting it
into the housing. (Figure B) 2
Continue to kit assembly
