All Models - Electric Booster Assembly - 40°F and 70°F Rise
4 109985 SEAL, ELECTRIC HEATER FLANGE 3
5 100003 NUT, PLAIN 1/4-20 SST 9
6 106482 WASHER, LOCK 1/4" SPLIT 9
7 328254 BRACKET, FRONT BOOSTER 1
8 100739 BOLT, 5/16-18 X 3/4" HEX HD. SST 2
9 102376 WASHER, FLAT 5/16" 4
10 106013 WASHER, LOCK 5/16" SPLIT 2
11 100154 NUT, PLAIN 5/16-18 SST 2
12 110561 THERMOSTAT, HIGH LIMIT WITH CAPILLARY 1
13 109069 THERMOSTAT, CONTROL WITH CAPILLARY 1
14 107967 NUT GRIP, 1/4-20 W/NYLON INSERT 3
15 106026 WASHER, FLAT 1/4" 3
16 108576 COVER, BOOSTER, NO CUTOUT 1
17 102505 PLUG, 3/4" NPT BRASS 1
18 100113 CAP, 3/4" NPT SST 1
19 414331 TANK BOOSTER 1
20 102490 NIPPLE, 3/4" NPT X 3-1/2" LG. BRASS 1
21 102442 ELBOW, 3/4" NPT X 90° BRASS 1
22 102392 BUSHING, REDUCING 3/4" NPT X 1/2" NPT BRASS 2
23 115101 CONNECTOR, MALE 1/2" NPT X 1/2" 37° FLARE JIC BRASS 2
24 113706 ELBOW, STREET 3/4" NPT X 45° BRASS 1
25 419003 HOSE ASSY 1/2" ID X 46" LG FLARE JIC 1
26 419012 HOSE ASSY 1/2" ID X 60" LG FLARE JIC 1
1 111235 HEATER, 5kW 1
2 107909 HEATER, 6kW 1
3 111235 HEATER, 5kW 1
69
Item
No. Part No. Description Qty.
208-220/60/3 40°F Rise - 16kW
1 111232 HEATER, 10kW 1
2 112059 HEATER, 12kW 1
3 111235 HEATER, 5kW 1
208-220/60/3 70°F Rise - 27kW
1 111236 HEATER, 5kW 1
2 114030 HEATER, 6kW 1
3 111236 HEATER, 5kW 1
230-240/60/3 40°F Rise - 16kW
1 111233 HEATER, 10kW 1
2 111334 HEATER, 12kW 1
3 111236 HEATER, 5kW 1
230-240/60/3 70°F Rise - 27kW
1 111237 HEATER, 5kW 1
2 114031 HEATER, 6kW 1
3 111237 HEATER, 5kW 1
460-480/60/3 40°F Rise - 16kW
1 111234 HEATER, 10kW 1
2 112060 HEATER, 12kW 1
3 111237 HEATER, 5kW 1
460-480/60/3 70°F Rise - 27kW
