Cut out area in wall or ceiling for
entrance of 6" (150 mm)
ductwork or 5" (125 mm)
ductwork with a reducing collar.
The installation procedure differs
depending on the model and venting
method.
Before beginning the installation:
^ Read all instructions.
^ Determine height (S), regarding the
user’s body height, i.e. a comfortable
height for the user.
However, the greater the distance the
less effectively cooking odors are
drawn in.
^ If the hood is fitted flush to the
ceiling, regard the possible unit
height when selecting the installation
height.
Standard unit height (H):
Air Extraction . . . . . . . . 29
5
/
16
" - 41
9
/
16
"
. . . . . . . . . . . . . . . . . . (745 - 1055 mm)
Recirculation. . . . . . . . 34
7
/
16
" - 46
11
/
16
"
. . . . . . . . . . . . . . . . . . (875 - 1185 mm)
To fit the lower chimney section, the
distance between the top of the
chimney and the ceiling must be at
least
7 /
8
" (20 mm).
Appliance dimensions
27
