Arming and disarming event displays, User check-in event displays – Master Lock XR20 User Manual
Page 28

24
XR20
User Menu
Arming and Disarming Event Displays
This displays any arming or disarming of system areas.
16-Character Display
Description
ARM 3 12 1017
Area 3 has been armed by user 12. Press
the left Select key for the area name.
Press the right Select key for the time
the arming occurred.
32-Character Display
Description
A RM 5:10P 10/ 17
The Perimeter was armed at 5:10 PM.
PERIM ET ER
Press any Select key to display the area
number and user number.
Arming Event Types - There are 2 event type you may see here:
ARM - User armed the system
DIS - User disarmed the system
User Check-in Event Displays
This shows when a user selected the pager Check-in feature from
the User Menu. See page 13 for more information.
16-Character Display
Description
CHECKIN 16 1017
User 16 selected the Checkin feature on
Oct. 17. Press the right Select key for
the Checkin time.
32-Character Display
Description
MSG 3: 31P 10 / 17
User 16 selected the Checkin feature
CHECKIN USER: 16
at 3:31 PM on Oct.17.
