PHYSICAL DIMENSIONS
PSW-4 SPECIFICATIONS
Frequency Response 1
Phase Response 1
Maximum SPL 1
Dynamic Range 2
(- 6db points)
Sub Frequency
Low Frequency
Type
Connector
Nominal Input Level
Type
Burst Capability 3
THD, IM, TIM
Connector
Automatic voltage selection
Operational Voltage range
Max Continuous RMS Current ( > 10 sec)
Burst RMS Current ( < 1 sec)
Max Peak Current During Burst
Soft Current Turn-on
Dimensions
Weight
Enclosure
Finish
Protective Grill
Rigging
±
4 dB from 32 Hz to 160 Hz
±
90
°
from 45 Hz to 110 Hz
136 dB peak@1 meter
> 110 dB
360
°
H; 180
°
V
60 Hz
18" diameter MS-18 cone
15" diameter MS-15 cone
10k
Ω
impedance, electronically balanced
XLR (A-3) male and female
+4 dBu
Complementary power MOSFET output stages (audio class AB/H)
1240 watts (620 watts/channel)
< .02 %
250V NEMA L6-20 (twistlock) inlet or IEC 309 male inlet 4
95-125 VAC and 208-235 VAC;50/60 Hz 5
Turn on: 85 VAc; Turn off: 134 VAC; 50/60 Hz
Turn on: 165 VAC; Turn off: 264 VAC; 50/60 Hz
@115V: 8A @230V: 4A @100V: 10A
@115V: 15A @230V: 8A @100V: 18A
@115V: 22Apk @230V: 11Apk @100V: 25Apk
Inrush current
< 12A @ 115V
21 1 ⁄ 4 " W x 39 1 ⁄ 4 " H x 30" D
177 lbs (80.3 kg) / shipping: 206 lbs (93.4 kg)
Multi-ply hardwood
Black textured
Perforated steel grill, charcoal-grey foam
Aircraft pan fittings (3 on both top and bottom). Working load for
each fitting is 600 lbs, which is
1 ⁄ 5 the cabinet breaking strength
(with straight tensile pull).
1. Subject to half space loading, measured with one-third
octave frequency resolution in fixed ISO bands.
2. Measured as the range between the peak SPL and the
A- weighted noise floor.
3. Nominal 8 Ω resistive load, pink noise, 100V peak.
4. Other connectors available.
5. The unit is rated at 95-125 VAC and 208-235 VAC, 50/60 Hz, to
satisfy EC standards for –10% to 6% AC line voltage
ALL UNITS IN INCHES
