REGULATORY APPROVAL
The 6000 series is tested to ANSI Z21.88-2002/CSA 2.33-2002 standards
and also approved for installation in an aftermarket manufactured (mobile)
home, where not prohibited by state or local codes. Consult local building
codes prior to installation
.
Tested to Canadian Standards Association’s CSAP.4.1-02 Testing Method
for Measuring Fireplace Efficiency.
OPTIONAL ACCESSORIES & SPECIFICATIONS
149 Cleveland Drive • Paris, Kentucky 40361
www.monessenhearth.com
MADE IN U.S.A.
To avoid personal injury or property damage, the product described by this brochure must
be installed, operated and maintained in strict compliance with the instructions packaged
with the product and all applicable building or fire codes. Contact local building or fire
officials about restrictions and installation inspection requirements. All photographs and
drawings on this brochure are for illustrative purposes only and are not intended for, nor
should they be used as a substitute for the instructions packaged with the unit.
Appearance and specifications of the product are subject to change without notice.
© 2004 Monessen Hearth Systems, Inc.
Variable Thermostat
Controlled Forced Air Blower
On/Off Remote
Control with 90
min. countdown
timer with
Receiver. On/Off Remote
Control with
Receiver.
7-Day
Programmable
On/Off Wireless
Wall Thermostat
with Receiver.
OPTIONAL ACCESSORIES
Brass Louvers Pewter Louvers
7-Day
Programmable
Thermostat
Remote Control
with Receiver. Touch Light™ Table
Top/Wall Mount
TLM On/Off and
TLT Thermostat
Remote Control
with Receiver.
Product Specifications
Width Height Depth
Actual
Design
Certifie
Circulating
Framing Actual Framing Actual Framing
Model
624DVSTC
624DVPFC
624DVC(L)/(R)C
Circulating CSA
Circulating CSA
Circulating CSA
BTU/H
44"
44"
44"
44-1/4"
43-1/2"
43-1/2"
40-15/16"
40-15/16"
40-15/16"
41-1/8"
41-1/8"
41-1/8"
23-3/4"
23-3/4"
24-1/2"
22-3/4"
22-3/4"
24"
25,000-36,000
624DVSTC 624DVPFC 624DVC(L)/(R)C
1/2" 5/8" 1/2" 5/8" 1/2" 5/8"
Drywall Drywall Drywall Drywall Drywall Drywall
A
1
44-1/4" 44-1/4" 43-1/2" 43-3/8" 43-1/2" 43-3/8"
A
2
40-5/8" 40-5/8" 39-7/8" 39-3/4" 39-7/8" 39-3/4"
B 41-1/8" 41-1/8" 41-1/8" 41-1/8" 41-1/8" 41-1/8"
C 22-3/4" 22-1/2" 22-3/4" 22-1/2" 24" 23-7/8"
Please refer to the installation manual for more detailed
framing instructions. For Remote Operation:
Designer Direct Vent Fireplace
Framing Dimensions
NAT
26,000-36,000
25,000-36,000 26,000-36,000
25,000-36,000 26,000-36,000
LP
624DVSTC See-Thru 624DVPFC Peninsula
624DVC(L)/(R)C Corner
Warning:
• It is recommended that the screen be used during operation of this log
set. Always ensure the screen has adequate spaces to allow for passage
of combustion air to the gas log set.
• Correct installation of the ceramic fiber logs, proper location of the
heater and periodic cleaning are necessary to avoid potential service
problems with sooting.
• Keep small children and animals away from the open flame of the gas
log set at all times.
• There may be a start-up odor associated with the heating of the logs.
The odor should diminish in 2-3 hours of operation with the burner at its
highest setting with the fan in the off position.
Standard
Thermostat
On/Off Remote
Control with
Receiver. Standard Thermostat
On/Off Remote
Control with 3-Speed
Automatic Blower
Control with Receiver.
• Medium trim kit available in black, brass and pewter (624DVSTC Only)
• Decorative arched fronts, frames and firescreen doors available
in gold, brushed pewter and black (624DVSTC Only)
Thermostat On/Off
remote control
with 3-step flame
height adjustment
and 3-speed
blower control
with Receiver.
