Revision 1.2 Page 15
® ®
6 Technical Specifications
As Maretron is constantly improving its products, all specifications are subject to change
without notice. Maretron products are designed to be accurate and reliable; however, they
should be used only as aids to navigation and not as a replacement for traditional navigation
aids and techniques.
Certifications
Parameter Comment
NMEA 2000
®
Level A
Maritime Navigation and Radiocommunication Equipment & Systems IEC 60945
FCC and CE Mark Electromagnetic Compatibility
NMEA 2000
®
Parameter Group Numbers (PGNs)
Description PGN # PGN Name Default Rate
Periodic Data PGNs 65001 Bus #1 Phase C Basic AC Quantities 10 times/second
65002 Bus #1 Phase B Basic AC Quantities 10 times/second
65003 Bus #1 Phase A Basic AC Quantities 10 times/second
65004 Bus #1 Average Basic AC Quantities 10 times/second
65005 Utility Total AC Energy 10 times/second
65006 Utility Phase C AC Reactive Power 10 times/second
65007 Utility Phase C AC Power 10 times/second
65008 Utility Phase C AC Basic Quantities 10 times/second
65009 Utility Phase B AC Reactive Power 10 times/second
65010 Utility Phase B AC Power 10 times/second
65011 Utility Phase B AC Basic Quantities 10 times/second
65012 Utility Phase A AC Reactive Power 10 times/second
65013 Utility Phase A AC Power 10 times/second
65014 Utility Phase A AC Basic Quantities 10 times/second
65015 Utility Total AC Reactive Power 10 times/second
65016 Utility Total AC Power 10 times/second
65017 Utility Average Basic AC Quantities 10 times/second
65018 Generator Total AC Energy 10 times/second
65019 Generator Phase C AC Reactive Power 10 times/second
65020 Generator Phase C AC Power 10 times/second
65021 Generator Phase C AC Basic Quantities 10 times/second
65022 Generator Phase B AC Reactive Power 10 times/second
65023 Generator Phase B AC Power 10 times/second
65024 Generator Phase B AC Basic Quantities 10 times/second
65025 Generator Phase A AC Reactive Power 10 times/second
65026 Generator Phase A AC Power 10 times/second
65027 Generator Phase A AC Basic Quantities 10 times/second
65028 Generator Total AC Reactive Power 10 times/second
65029 Generator Total AC Power 10 times/second
65030 Generator Average Basic AC Quantities 10 times/second
Response to Requested PGNs 126464 PGN List (Transmit and Receive) N/A
126996 Product Information N/A
126998 Configuration Information N/A
Protocol PGNs 059392 ISO Acknowledge N/A
059904 ISO Request N/A
060928 ISO Address Claim N/A
065240 ISO Address Command N/A
126208 NMEA N/A
Maretron Proprietary PGNs 128720 Configuration N/A
