95-7322 DASH DISASSEMBLY
HYUNDAI AZERA 2006-2010
Remove (3) Phillips screws from the
top of the radio trim panel. (Figure D) 5
Remove (2) Phillips screws from
under radio trim panel. (Figure E) 6
Unclip and remove the entire trim
panel surrounding the radio. (Figure F) 7
Remove (4) Phillips screws securing
the radio. Unplug and remove radio.
(Figure G) 8
Continue to kit assembly.
2
D
E
TEMP
TEMP
MODE
A/C
OFF
AUTO
DUAL
PASS
F G
