WIRING DIAGRAM
5
1 HOUR
2
3
4
5
T-DOWN
6
7
8
9
10
11
12
13
14
15
16
RDM
PRO
MODE
VOLUME
POWER
STOP
OPEN
17
CONTROL LOCATIONS
Superior disc reading ability: Able to read CD
PLAY
DISP
BAND
MINUTE
REP
TUN
EJECT
1
2
16
14 13 12 11 10 9 8 7 6
3
4
5
15
17
T-UP
Design and specifications subject to change without notice
Frequency response:10HZ-20KHZ
Channel separation @ 1KHZ:>65dB
D/A converter:1Bit
S/N:
60dB
Tuning range:87.5MHZ-108MHZ
Usable sensitivity:20dBu
Stereo separation @ 1KHZ:30dB
Frequency response:50HZ-10KHZ
Tuning range:520KHZ-1600KHZ
Usable sensitivity:40dBu
Frequency response:50Hz-3KHz
Power output:7W 4 @ 4 ohms,14.4 VDC
Operating voltage:11-14.4 VDC, negative ground
Speaker output impedance:4~8 ohms
Line output voltage:200mv-400mv
Dimensions:7 ”
7 ” 2 ” (178 178 51mm)
AM TUNER
FM TUNER
GENERAL
CD PLAYER
SPECIFICATIONS
CONNECTIONS
ANTENNA
SOCKET
WHITE
R
L
RCA OUT
RED
GRAY
BLUE ANTENNA
POWER
RED
YELLOW
BLACK GND
ACC
B+
A B
2
4
6
8
1
3
5
7
2
4
6
8
1
3
5
7
A4:RED ACC
A5:BLUE ANTENNA
A7:YELLOW B+
A8:BLACK GND
B1:VIOLET + (RR)
B2:VIOLET/BLACK - (RR)
B3:GRAY + (RF)
B4:GRAY/BLACK - (RF)
B5:WHITE + (LF)
B6:WHITE/BLACK - (LF)
B7:GREEN + (LR)
B8:GREEN/BLACK - (LR)
Right Front
Gray/Black(-)
Gray(+)
Left Front
White/Black(-)
White(+)
Right Rear
Violet/Black(-)
Violet(+)
Left Rear
Green/Black(-)
Green(+)
3A
1A
