Figure 4. Rear panel view of the MIL-S500 switch
Auto-sensing ports for speed and Duplex
Five Auto-sensing RJ-45 ports for 10Base-T or 100Base-TX connections.
DC Power Connector
Plug this connector female end into this device, and the male into a power
outlet. Supported input voltages 9 VDC at 700 mA.
Auto-sensing for MDI/MDIX
No need for crossover
LED-Indicators 5
Figure 5. Front panel view of LED indications
The Table lists the LEDs available and their respective function.
LED Status Color Description
Power On Green The hub is supplied with suitable power.
On Green The port is connecting with 100Mbps.
100Mbps
Off
The connection between the hub and the device is
10Mbps, if the LINK/ACT light is on.
7
