Instrument Cluster
7 8
NOTE: The tire pressure should be set when tires are cold. Large changes in ambient
temperatures or altitude will cause tire pressure change and may cause TPMS warning
light to illuminate.
Low Fuel Level
TCS OFF
(Traction Control System)
KEY Warning Light ( RED )
Advanced key not detected
or transmitter battery is dead.
KEY Indicator Light ( gREEN )
On: Advanced key detected; engine
is ready to start
Flashing: Advanced key battery is low.
Check Fuel Cap
Electronic Steering Lock
Indicates steering wheel is locked.
Light-On (Exterior Lights)
Tire Pressure
Monitoring System
Tire pressure may be low in one or
more tires.
BSM OFF
(Blind Spot Monitoring)
DSC OFF
(Dynamic Stability Control)
Charging System
Malfunction
Powertrain Malfunction/
Reduced Power
ABS
(Antilock Brake System)
Malfunction
Check Engine Light
Brake Warning Light
Parking brake on/low brake
fluid/malfunction
Turn Signal/
hazard Warning
FUEL gAUgE TAChOMETER
BSM
OFF
TCS
OFF DSC
OFF
INSTRUMENT
CLUSTER DIMMER
AMBIENT
TEMPERATURE
gLOSSARY OF WARNINg AND INDICATOR LIghTS
NOTE: See Owner’s Manual for more details and explanations.
Automatic Transmission
Malfunction
headlight high-Beam
Traction Control System
(TCS)/Dynamic Stability
Control (DSC)
On: TCS/DSC malfunction
Flashing: TCS/DSC operating
A/T Shift Position Indicator
Air Bag/Front Seat Belt
Pretensioner System
On or Flashing: Air Bag malfunction
Low Engine Oil Pressure
Security Indicator Light
Door-Ajar
Seat Belt
Seat Belt unbuckled/malfunction
Cruise Main Indicator
Light
( AMBER ) /Cruise Set
Indicator Light ( gREEN )
Low Washer Fluid Level
SPEEDOMETER ENgINE COOLANT
TEMPERATURE gAUgE
ODOMETER/
TRIP METER
SELECTOR
ODOMETER/
TRIP METER
gEAR INDICATOR
