PCI-CTR05 User's Guide Specifications
J1
Table 4-8. Main connector J1 pin out
Pin Signal Name
1 IRQ INPUT
2 IRQ ENABLE
3 DOUT7
4 DOUT6
5 DOUT5
6 DOUT4
7 DOUT3
8 DOUT2
9 DOUT1
10 DOUT0
11 GND
12 CTR5GATE
13 CTR5CLK
14 CTR4GATE
15 CTR4CLK
16 CTR3GATE
17 CTR3CLK
18 CTR2GATE
19 CTR2CLK
20 PC
+5V
21 DIN STROBE
22 DIN7
23 DIN6
24 DIN5
25 DIN4
26 DIN3
27 DIN2
28 DIN1
29 DIN0
30 OSC
OUT
31 CTR5OUT
32 CTR4OUT
33 CTR3OUT
34 CTR2OUT
35 CTR1OUT
36 CTR1CLK
37 CTR1GATE
4-4
