115
Instrument cluster
Technical
data
Instruments
and controls
Operation
Driving
Instrument
cluster display
Practical hints
Car care
Index
1
Knob for instrument cluster illumination,
see page 116
2
Engine malfunction indicator lamp, see page 296
3
Brake fluid low or parking brake engaged,
see page 307
4
Supplemental restraint system (SRS) malfunction
indicator lamp, see page 299
5
Coolant temperature gauge, see page 117
6
Outside temperature indicator, see page 117
7
Fuel gauge with reserve warning lamp, see page 299
8
Left turn signal indicator lamp, see combination
switch on page 164
9
Speedometer, see page 118
10
Electronic stability program (ESP) warning lamp,
system is adjusting to road conditions, see page 301
11
Distance warning lamp – vehicles with Distronic
(DTR), distance to the vehicle ahead is insufficient,
see page 270 and page 301.
Vehicles without Distronic: It illuminates with the
electronic key in starter switch position 2. It should
go out when the engine is running.
12
Multifunction display, see page 120
Malfunction and warning messages in the
multifunction display, see page 303
13
Trip odometer, see page 119 and 124
14
Main odometer, see page 124
15
Right turn signal indicator lamp, see combination
switch on page 164
16
Tachometer, see page 119
17
Gear range indicator display, see selector lever
positions on page 238
18
Digital clock
To set the time, see COMAND operator’s manual
19
Antilock brake system (ABS) malfunction indicator
lamp, see page 300
20
High beam headlamp indicator,
see exterior lamp switch, page 159, and
combination switch, page 164
21
Fasten seat belts, see page 302
22
Reset button
