Monessen
Direct Vent Gas Fireplace
Standard Features Trims & Options
Model HBDV300 HBDV400
BTU / HR 16,000-23,000 NG / 18,000-23,000 LP 19,000-27,000 NG / 20,000-26,000 LP
FE Ratings (Cdn. Fireplace Efficiency) 63.5 NG / 71.4 LP 67.3 NG / 70.7 LP
Afue Efficiency UP TO 71% UP TO 71%
Thermal Efficiency UP TO 85% UP TO 85%
Dimensions (Actual) 33 1/16”W x 37” H x 14” D 37 1/16”W x 40 1/2” H x 16” D
Dimensions (Framing) 33 1/2”W x 37 1/4” H x 14” D 37 1/2”W x 40 7/8” H x 16” D
Viewing Area 18”H x 27”W (486 SQ. IN.) 20 3/8” H x 29” W (591 SQ. IN.)
Blower OPTIONAL OPTIONAL
Your Monessen Dealer:
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
• Available 33" & 36" (rear/top convertible)
with standard ceramic glass and andirons
• 23,000 & 27,000 BTU
• Field convertible vent technology to vent
horizontally or vertically, and from natural to
propane gas
• Removable unitized louver system for top
and bottom
• Illustrated consumer-friendly deluxe control
panel with easy lift off capabilities
• Ember bed burner with fiber ceramic logs
• AFUE rated and P4 listed
• Variable Hi/Lo flame control
• Field installed Cottage Clay or Cottage Red
firebrick. Note: Firebrick is required for all
HBDV models.
Deluxe control panel
Also Available:
• Brass, pewter and black trims and louvers
• Mesh glass cover
• 160 cfm forced air blower
• Remote controls
Cottage Red Pewter Louvers Brass Louvers Cottage Clay
Firebrick Options Louver Options
• Medium and curved trim kits available for HBDV
• Designer Facings Available
Medium Gold Medium Black Medium Pewter
