1
95-7418
Disconnect the negative battery
terminal to prevent an accidental
short circuit. 1
Unclip and remove the trim panel
surrounding the climate controls.
(Figure A) 2
2002-2004 NISSAN ALTIMA
Remove (1) Phillips screw (bottom
right side of panel) securing the
panel surrounding the radio then
unclip and remove the panel.
(Figure B,C) 3
Remove (4) Phillips screws securing
radio to remove. (Figure D) 4
Remove the screws securing the
factory brackets to the radio and
remove brackets. (Retain brackets
for re-use during kit assembly.) 5
DASH DISASSEMBLY
A
B
D
C
