Middleby Marshall PS540-Series Ovens PS540G - Manual (Page 67)

63
ENGLISH
SECTION 6
PARTS LIST
GAS BURNER AND PIPING ASSEMBLY
ITEM
QTY.
P
/N
DESCRIPTION
1
1
50275
ASSY, BURNER/BLOWER
2
1
36937
GASKET, DS-22 BURNER FLANGE
3
1
22550-0006
FLANGE, DS-22 BURNER
4
a
1
50640
ORIFICE, MAIN BURNER - 5/8 × 27 THD (0.1935
″
Ø) (NATURAL GAS)
4
b
1
50641
ORIFICE, MAIN BURNER - 5/8 × 27 THD (0.120
″
Ø) (PROPANE GAS)
5
1
23015-0004
COUPLING, PIPE NPT 1/2
″
6
1
30002
PLUG, SQ HD 1/8 NPT BR
7
1
48742
BUSHING, 1/2-1/8 NPT REDUCER
8
1
45667
TEE, PIPE 1/2
″ Ч 1/2
″ Ч 1/2
″
9
1
31238
NIPPLE, 1/2 × 4 BLK PIPE
1
0
1
60679
ASSY, GAS VALVE
1
1
1
23122-0004
ELBOW, 90° PIPE (150#MI) 0.500
1
2
1
23153-0004
NIPPLE, CLOSE BLK 1/2
1
3
1
37000-0781
ASSY, 1/2
″ PIPE CLAMP PS200
1
4
1
37869
NIPPLE, BLK 1/2 Ч 3-1/2
