owners manual
6
Bookshelf/Entertainment Unit
Placement
The small size and Omnipolar dispersion of the
versatile OMNISAT permits them to be easily
placed, among other places, in a bookshelf. If this
is your preferred placement, affix the isolating
pads provided to the bottom of the speaker to
help isolate the speaker from the shelf and
eliminate any transference of resonance. To
maximize the Omnipolar dispersion potential,
bring the speaker as close to the front of the
cabinet as possible. See Diagram 9.
CONNECTIONS
The Mirage OMNISAT is equipped with high
quality binding posts that permit the use of
banana plugs, spades, or a bare wire connection.
Turn them counterclockwise to loosen, clockwise
to tighten.
Connect the speaker wire from the positive
(RED +) terminal on the amp to the positive
(RED+) terminal on the speaker. Connect the
negative (BLACK-) terminal on the amplifier to
the negative (BLACK-) terminal on the speaker.
See Diagram 7.
OMNISAT
System Type: Magnetically Shielded
Omnipolar Satellite
Frequency
Response:
70 Hz-20KHz, +/- 3dB
Tweeter: 1” (25mm) PTH™
Pure Titanium Hybrid
Woofer: 4.5” Polypropylene Titanium
Deposit Hybrid cones with
butyl surrounds
Power Handling: 150 watts
Crossover Points: 2.2 kHz
Room Efficiency: 89 dB
Impedance: 8-ohm nominal,
4 ohm minimum
Recommended
Amplifier Power:
10 to 150-watts
RMS/Channel
Inputs: High Quality 5-way
Binding Posts
Weight: 7 lbs
3.2 kg
Dimensions: inches: 8 x 6-1/4 x 8
(HxWxD) cm: 20.3 x 15.8 x 20.3
LF-150
System Type: Magnetically Shielded,
Front Ported Subwoofer
Amplifier Type: Discrete MOSFET Class A/B
Power Output: 600 watt dynamic peak,
150 watts continuous
Woofer: 10” Polypropylene Titanium
Deposit Hybrid
Magnet Size: 28 oz.
Voice Coil
Diameter:
1.5”
Frequency
Response:
23Hz-120Hz - 3db
Phase Switch: 0/180
Variable
Low Pass Filter:
40Hz -120Hz @ 18 db/octave
Inputs: Low level input, crossover
bypass, high level
Outputs: High level
Dimensions: inches: 12-1/2 x 19-3/4 x 16-1/4
cm.: 31.5 x 50 x 39.4
Weight: 45 lbs.
20.4 kg
