Condition

Item(s) to Check

LED " " (green) is off,

Check that UPS is plugged in, AC power is

UPS has no output

"on" to UPS and UPS is turned "on".

UPS has little or no back-up time

Charge UPS overnight and retry. After 3-5
years, consider replacing batteries if back-up
time is short (MGE P/N 3088201000).

LED "

" flashes (green)

Many low voltage events or poor voltage and

audible alarm beeps often

regulation at receptacle. Try another

(UPS transfers to battery)

receptacle.

LED " " (red), beeping

Potential internal failure. Restart UPS. Call for

audible alarm

assistance If red LED reappears.

LED " " (green),

UPS operation on battery due to utility

1 beep every 10 seconds

power failure

LED " " (green),

UPS operation on battery

1 beep every 3 seconds

and battery near exhaustion

LED " " (red),

UPS lightly or heavily overloaded.

with beeping audible alarm

Reset circuit breaker on UPS if necessary.
Reduce load and restart UPS

LED " " (green) and

Faulty battery. Recharge battery.

LED " " (red)

Replace battery if fault reappears.

MGE maintains a toll-free number for technical support for US and Canadian customers. Call for
assistance as shown in the "Service and Parts" section of this manual or visit our web site at:
www.mgeups.com

MGE UPS Systems

Ellipse User’s Manual

page 7

Troubleshooting

Model Identification

Ellipse

Communications

Fax,

MGE Part

UPC Codes

Model

Modem/Network

Number

Protection

300 VA

USB

89301

635760893014

300 VA

–

Fax Modem

89303

635760893038

500 VA

USB

89304

635760893045

500 VA

RS232

89305

635760893052

500 VA

–

Fax Modem

89306

635760893069

650 VA

RS232

89308

635760893083

800 VA

USB

89310

635760893106

1200 VA

RS232

89314

635760893144



MGE GREEN SWEEP

Call MGE to return your UPS for free
recycling to a US EPA-certified recycling
center and help protect our environment.

MGE UPS Systems

86-153506-00 Rev. A01

page 6

Run Time Chart for Various Loads

25% Load

50% Load

75% Load

100% Load

Model

300

500

650

800

1200

Product Specifications

300 / 500

650 / 800

1200

UPS VA rating:

300 / 480

650 / 800

1200 (10 A)

(2.3 / 4 A)

(5.7 / 6.7 A)

(10 A)

UPS W rating:

180 / 285

420 / 520

780

Surge suppressor

900 / 720

550 / 400

VA rating:

(7.5 A / 6 A)

(4.6 A / 3.3 A)

Input/Output voltage:

106/120/127 VAC*

50/60 Hz

Deep discharge

4 hrs. max

protection:

run time

UPS back-up time:

6/4 minutes

7/4 minutes

4 minutes

UPS output

Modified sine

wave shape:
Load shedding

3 grouped

receptacles:
Surge suppressor

185

joule rating:
Input cord:

6 foot with rotating

NEMA 5-15 plug

Circuit breaker:

10 amp

Agency approvals:

UL, cUL, FCC

Recharge time:

8 hours

Battery:

1 each 12 volt, 5 Ah

2 each 12 volt, 5 Ah

3 each 12 volt, 5 Ah

Battery life:

3 years

UPS current limit:

>100% Load

Operating temperature:

0-35 C/32-96 F

Storage temperature:

0-50 C/32-122 F

Size:

10" X 10" X 3.2"

12" X 12" X 3.2"

14" X 14" X 3.2"

Weight:

9 lbs.

13 lbs.

18 lbs.

Warranty:

2 years

parts and labor

Accessories:

6' fax/modem cable,

communication cable

(RS232 or USB)

* Input voltage and transfer voltage to battery is user selectable. Go to UPS Manager/UPS Driver in

Solution Pac software to adjust.

Performance & Product Specifications
