Mazda 2005 3 4-DOOR - Manual (Page 312)

Black plate (312,1)
Specifications
qEngine
Item
Model
2.0-liter engine 2.3-liter engine
Type DOHC-16V in-line, 4-cylinder
Bore×Stroke 87.5 × 83.1 mm (3.44 × 3.27 in) 87.5 × 94.0 mm (3.44 × 3.70 in)
Displacement 1,999 ml (1,999 cc, 121.9 cu in) 2,261 ml (2,261 cc, 137.9 cu in)
Compression ratio 10.0 9.7
qElectrical System
Item Classification
Battery 12V-40AH/5HR, 12V-52AH/5HR, 12V-55AH/5HR
Alternator 12 V - 90 A
Starter
2.0-liter engine 12 V - 1.0 kW
2.3-liter engine 12 V - 1.4 kW
Spark-plug number L303 18 110 *
Spark-plug gap 1.25
―1.35 mm (0.049―0.053 in)
* ex factory
NOTE
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on
the iridium alloy and platinum tips could be damaged.
qLubricant Quality
Lubricant Classification
Engine oil
Refer to the recommended SAE viscosity numbers on page
8-13.
Manual transaxle oil
Any temperature
API Service GL-4 or GL-5
SAE 75W-90
Above 10°C (50°F)
API Service GL-4 or GL-5
SAE 80W-90
Automatic transaxle fluid ATF M-V
Power steering fluid ATF M-III or equivalent (e.g. Dexron® III)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
10-4
Specifications
Mazda3_8T66-EA-04H_Edition1 Page312
Thursday, June 24 2004 5:20 PM
Form No.8T66-EA-04H
