Page 3
30cc Back Pack Blower
Date:7-28-2009
No.
Parts No.
Description
Q
P Code
ASB3206
PARTS LIST
27-10
9SGKB-4.8-12
SCREW
1
120
28
9228-MD0107
PAWLS ASS'Y
1
120
29
9228-334521
AIR FILTER COVER
1
120
30
9183-334501
AIR FILTER
1
120
31
9SGEB-05-52
SCREW
2
120
32
9228-334519
AIR BOX / CHOKE ASS'Y
1
120
33
9287-334501
CARBURETOR
1
120
34
9014-334505
CARBURETOR GASKET
1
120
35
9SKKB-05-19
SCREW
4
120
36
9211-334503
PLATE
1
120
37
9012-334501
GROMMET
1
120
38
9072-334501
INSULATOR 1
120
39
9014-334506
INSULATOR GASKET
1
120
40
9157-332101
SEAL 1
120
41
9228-334501
自
CRANKCASE ASS'Y
1
120
42
9DB-620101
BEARING
2
120
43
9014-334502
GASKET, CRANKCASE SIDE
1
120
44
9157-334501
SEAL 1
120
45
9CB-32
C RING
1
120
46
9169-334501
FLYWHEEL
1
120
47
9228-334506
FUEL TANK ASS'Y
1
120
47-1
9228-334505
FUEL CAP ASS'Y
1
120
47-2
AO9066-GP0201-US888
VENT ASS'Y
1
120
47-3
9228-GP0513
KIT HOSES, FILTER AND GROMMET
1
120
48
9SKKBY05-18
SCREW
3
120
49
9127-320602
COUPLER
1
120
50
9WFZ-12.1-30
WASHER
1
120
51
6NGZ-05
NUT
2
120
52
9038-320603
SCREW HOUSING 116C YELLOW
1
120
53
6NDE-06
NUT
2
120
54
9012-320601
MOUNTS ANTIVIBRATION
3
120
55
9SRCBM05-30
SCREW
4
120
56
9151-320601
IMPELLER
1
120
57
9122-320601
DISC FIXED
1
120
58
9NAC-08
NUT
1
120
59
9038-320604
SCREW HOUSING 116C YELLOW
1
120
60
9SKKBY8/16-0.75
SCREW
6
120
