FEATURES
• Patented state-of-the-art power supply and output stage
• High mass extruded aluminum heatsink for maximum thermal management and
bulletproof reliability
• Adjustable HP/LP Crossover - 40Hz-350Hz, 12dB/oct for maximum system
design flexibility
• Stereo Gain Control for precision matching between your amplifier and radio
• Fully adjustable Bass Boost - 40Hz, 0-18dB to enhance the low frequency
experience in your vehicle
• Remote subwoofer level control included allows you to fine tune the bass from
the driver’s position when you switch between different musical styles
• High Level Input with patented Smart Engage Auto Turn-on for easy installation
with factory radios
• CEA 2006 Compliant. All power ratings are not created equal. CEA 2006
Compliance ensures that the power of this amplifier is measured according to
strict standards dictated by the Consumer Electronics Association.
2
SPECIFICATIONS
RMS per channel
@ 4Ω (≤ 1%
THD+N)
50 Watts 75 Watts 100 Watts 150 Watts
RMS per channel
@ 2Ω (≤ 1%
THD+N)
100 Watts 150 Watts 200 Watts 300 Watts
RMS bridged
channels @ 4Ω
(≤ 1% THD+N)
200 Watts 300 Watts 400 Watts 600 Watts
Signal to Noise
Ratio
80 dBA 80 dBA 80 dBA 80 dBA
Frequency
Response
20Hz to 20kHz
(-3dB)
20Hz to 20kHz
(-3dB)
20Hz to 20kHz
(-3dB)
20Hz to 20kHz
(-3dB)
Maximum Input
Signal
5V 5V 5V 5V
Maximum
Sensitivity
100mV 100mV 100mV 100mV
THD+N
(Distortion)
<0.25%
(reference:1W
output)
<0.25%
(reference:1W
output)
<0.25%
(reference:1W
output)
<0.25%
(reference:1W
output)
MXA2002 MXA3002 MXA4002 MXA6002
