Dimensions
(unit = mm)
PIN RS-422/485 (4W)
RS-485 (2W)
1
TxD-(A)
–
2
TxD+(B)
–
3
RxD+(B)
Data+(B)
4
RxD-(A)
Data-(A)
5
GND
GND
6
–
–
7
–
–
8
–
–
9
–
–
6 7 8 9
1 2 3 4 5
PIN
RS-232
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
6 7 8 9
1 2 3 4 5
PIN
RS-232
RS-422/485 (4W)
RS-485 (2W)
1
DCD
TxD-(A)
–
2
RxD
TxD+(B)
–
3
TxD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
9
–
–
6 7 8 9
1 2 3 4 5
1
12-48
3
Port 1 RS-422/485
12-48
5
Port 1 RS-232/422/485
12-48
NPort 5110
NPort 5130
NPort 5150
Pin Assignment
NPort 5110
NPort 5130
NPort 5150
