Metra Electronics HONDA RIDGELINE 99-7870G - Manual (Page 3)

99-7870
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit. 1
Unclip and remove entire panel sur-
rounding radio and a/c control all the
way over to left side of steering
wheel. (Figure A) 2
HONDA RIDGELINE 2005-2010
Remove (5) Phillips screws securing
the radio and pocket assembly.
(Figure B) 3
Remove (2) Phillips screws (1 per
side) securing factory pocket to
radio/pocket bracket assembly.
(Figure C, D) 4
DASH DISASSEMBLY
A
B
C D
