OM-486 Page 19
5-2. Remote Amperage/Voltage Control
1 Remote 14 Receptacle RC1
Connect optional remote control to
RC1 (see Section 4-8).
2 Remote Hand Control
(Optional)
3 Remote Foot Control
(Optional)
.
Engine runs at weld/power
speed whenever a device con-
nected to the remote 14 recep-
tacle is running.
ST-801 943-B / ST-189 925-A / S-0769 / S-0774
1
Process = Stick (SMAW)
In Example:
Set Polarity Switch
2
Max = 140 A CC/DC
Min = 40 A CC/DC
Max (140 A DC)
Min (40 A DC)
Set Remote Control
Switches
Set Process and
A/V Control
Adjust Remote Control
(Stick Welding Only)
3
