C-9
Intel ICH7R SATA RAID
Installing Software
Install Driver in Windows XP / 2000
† New Windows XP / 2000 Installation
The following details the installation of the drivers while installing W indows XP /
2000.
1. Start the installation:
Boot from the CD-ROM. Press F6 when the message "Press F6 if you need
to install third party SCSI or RAID driver" appears.
2. W hen the W indows XP Setup window is generated, press S to specify an
Additional Device(s).
3. Insert the driver diskette Intel IAA RAID XP Driver For ICH7R (NH82801GR)
into drive A: and press
4. Choose the driver Intel(R) 82801GR SATA RAID Controller from the drop-
down list that appears on W indows XP Setup screen, and press the
key.
5. Press
additional devices to be installed, do so at this time. Once all devices are
specified, press
6. From the W indows XP/2000 Setup screen, press the
now load all device files and then continue the Windows XP/2000 installation.
† Existing Windows XP/2000 Driver Installation
1. Insert the MSI CD into the CD-ROM drive.
2. The CD will auto-run and the setup screen will appear.
3. Under the Driver tab, click on Intel IAA RAID Edition.
4. The drivers will be automatically installed.
† Confirming Windows XP/2000 Driver Installation
1. From W indows XP/2000, open the Control Panel from My Computer fol-
lowed by the System icon.
2. Choose the Hardware tab, then click the Device M anager tab.
3. Click the "+" in front of the SCSI and RAID Controllers hardware type. The
driver Intel(R) NH82801GR SATAII RAID Controller should appear.
Important
Please follow the instruction below to make an
“Intel IAA RAID XP Driver
For ICH7R (NH82801GR)
” for yourself.
1. Insert the MSI CD into the CD-ROM drive.
2. Click the
“Browse CD” on the Setup screen.
3. Copy all the contents in the: \\IDE\Intel\ICH7R\Floppy to a formatted
floppy disk.
4. The driver disk for ICH7R RAID controller is done.
