Wireless Network Access Point
Chapter 1: Introduction
The Instant Wireless TM Network Access Point
Don’t be bound by cabling restrictions any longer! The Instant Wireless™
Network Access Point from Linksys delivers the freedom to configure your net-
work your way. Utilization of state-of-the-art wireless technology gives you the
ability to set up workstations in ways you never thought possible; no cables to
install means fewer expenses and fewer hassles.
The Instant Wireless™ Network Access Point’s high-powered antennae offer a
range of operation of up to 1500 feet, providing seamless roaming throughout
your LAN infrastructure. Advanced user authentication ensures a high level of
security for wireless networking, while easy-to-use Windows-based diagnostics
and statistics tools ensure that you’ll always be in control. Best of all, the
Instant Wireless™ Network Access Point features easy installation—just plug
it in and you’re ready to go!
When all these features come together in one compact, lightweight, and power-
efficient unit, you have the ultimate in flexible networking—the Linksys
Instant Wireless™ Network Access Point.
Features
• Highly Efficient Dipole Antennae Provide Extensive Range of Operation
• Enjoy Your Wireless Office Beyond the Range of Ethernet Networking
• Auto Fall-Back Data Rate for Long-Distance Communication and Noisy
Environments
• High-Speed Data Transfer Rate Up to 11 Mbps
• Interoperable with IEEE 802.11b (DSSS) 2.4GHz-Compliant Equipment
• Features Roaming and Network Traffic Filtering
• Extensive Operating Range Supports up to 300 ft. (Indoors) and 500 feet
(Outdoors)
• Up to 256-Bit Wired Equivalent Privacy Supported
• Free Software Driver Upgrades
• Compatible with Virtually All Major Operating Systems
• Free Technical Support—24 Hours a Day, 7 Days a Week for North America
Only
• 1-Year Limited Warranty
Table of Contents
Chapter 1: Introduction 1
The Instant Wireless TM Network Access Point 1
Features 1
Package Contents 2
System Requirements 2
Chapter 2: Planning Your Wireless Network 3
Network Topology 3
Roaming 3
Chapter 3: Getting to Know the Wireless Network Access Point 4
The Wireless Network Access Point’s Ports 4
The Wireless Network Access Point’s LEDs 5
Chapter 4: Connecting the Wireless Network Access Point 6
Chapter 5: Setting Up the Wireless Network Access Point 7
Chapter 6: Configuring the Wireless Network Access Point 14
The Setup Tab 14
The Password Tab 19
The Status Tab 20
The Help Tab 22
The Filter Tab 23
The Wireless Tab 25
Appendix A: Troubleshooting 28
Frequently Asked Questions 28
Appendix B: Setting Up the TCP/IP Protocol 32
Setting Up TCP/IP in Windows 32
TCP/IP Setup for Windows 95, 98, and Millennium 33
TCP/IP Setup for Windows NT 4.0 34
TCP/IP Setup for Windows 2000 35
Appendix C: Glossary 36
Appendix D: Specifications 44
Environmental 45
Appendix E: Warranty Information 46
Appendix F: Contact Information 47
1
Instant Wireless TM Series
