Makita 6347DWDE User Manual
Page 2
Item
Part
Qty.
Item
Part
Qty.
No.
No.
Used
Description
No.
No.
Used
Description
2
266130-9 10 TAPPING SCREW BIND PT 3X16
4
344391-2
2 BIT HOLDER
5
183451-3
1 HOUSING SET (INCL. FIG. 20 & 21)
6
417879-6
1 MODE CHANGE LEVER
7
125102-2
1 SPEED CHANGE LEVER ASS'Y (INCL. 2
EA. 231433-0 COMPRESSION SPRING 4)
8
232182-2
1 LEAF SPRING
9
417880-1
1 F/R CHANGE LEVER
10
638143-4
1 SWITCH UNIT (INCL. 643918-8 BATTERY
HOLDER, & 650528-4 SWITCH C3SA-MH
SINGLE W/O LOCK VARIABLE)
12
251464-3
1 - FLAT HEAD SCREW M6X22
14
125160-8
1 GEAR ASS'Y
15
638138-7
1 YOKE UNIT
16
619082-7
1 ARMATURE
17
638139-5
1 ENDBELL COMPLETE
18
191971-3
1 CARBON BRUSH CB-430 2PC./SET
19
643954-4
2 BRUSH HOLDER CAP
20
819064-1
1 MAKITA MARK
21
183451-3
1 HOUSING SET (INCL. FIG. 5 & 20)
22
231829-5
1 TENSION SPRING 2
23
233353-4
1 COMPRESSION SPRING 2
24
417966-1
1 LOCK LEVER
ACCESSORIES
13
763158-3
1 KEYLESS DRILL CHUCK 13
A01 414938-7
2 BATTERY COVER
A02 784614-0
1 +- BIT 2-45
A03 824660-2
1 PLASTIC CARRYING CASE
(INCL. 1 EA. 417723-7 HANDLE,
& 2 EA. 417724-5 LATCH)
A04
DC1803
1 BATTERY CHARGER
A05 193159-1
2 18V BATTERY 1834
05-02
2
Model 6347DWDE
