To remove the bed extender:
1. Extend the bed extender.
2. Pull the lever on each side of
the bed extender to unlock it.
Make sure the locking clip screws
are loose before removing the bed
extender.
3. Press the locking clips below
the middle bar and lift the bed
extender out of the channels on
the “D” pillar.
To install the bed extender, follow the removal procedure in reverse
order.
