Parts list – MTD V560 User Manual
Page 15

15
8
Parts List
Ref. Part No.
Description
1
750-04405
Slev. Spacer 1.8” Lg.
2
750-04404
Sleeve Spacer 9.10” Lg.
3
710-0654A
Self-Tapping Sems Screw
4
787-01278
21” Deck 3 in 1 SP
5
710-0599
TT Screw 1/4-20 x 0.5
6
736-0270
Bell Washer
7
687-02055
Hinged Mulch Plug Assembly
8
17032A
Chute Deflector Adapter
9
732-1014
Torsion Spring
10 747-0710
Hinge Pin
11
618-04377A Transmission Assembly
12 687-02193
Height Adj. Assembly - LH
687-02194
Height Adj. Assembly - RH
13 787-01298
Front Height Adj. Plate - RH
787-01299
Front Height Adj. Plate - LH
14 687-02044
Pivot Plate Assembly
15 732-0706
Front Lever - RH
732-0707
Front Lever - LH
16 782-5002B
Front Baffle
17 712-04065
Flange Lock Nut, 3/8-16
18 734-2042
Front Wheel, 8 x 2.125, Zag
634-0190
Front Wheel, 8 x 1.8, Bar
19 734-04093
Rear Wheel, 12 x 2.125, Zag
Ref. Part No.
Description
734-04082
Rear Wheel, 12 x 1.8, Bar
20 710-04531
Screw 1/4-20 x .390
21 717-1762
Gear 14T RH FWD RH
717-1761
Gear 14T LH FWD LH
22 715-0221
Dowel Pin
23 782-7551A
Wheel Dust Cap
24 716-0102
Snap Ring
25 736-0474
Flat Washer
26 710-0216
Hex Screw, 3/8-16 x.75
27 736-0447
Wave Washer
28 682-0015
Bearing Assembly
29 720-0426
Adjustment Knob
30 710-1652
TT Scr. w/Washer 1/4-20 x.625
31 738-0507B
Shoulder Scr.500 Dia. x.434
32 687-02039A Pivot Arm Assembly - RH
687-02040A Pivot Arm Assembly - LH
33 732-0866
Rear Spring Lever
34 720-0312
Foam Grip
35 687-02280
Handle Bracket Assembly - LH
687-02279
Handle Bracket Assembly - RH
36 731-0981A† Hub Cap
37 736-0182†
Washer, Sprg, .500 x 1.00 x .022
To order replacement
parts, call
1-800-800-7310
or visit us on
the web at
www.mtdproducts.com
† If Equipped
