1. Tripod legs
2. Equatorial mount
3. R.A. flexible cable control
4. Dec. flexible cable control
5. Counterweight
6. Counterweight shaft
7. Counterweight lock
8. Safety washer/thumbscrew
9. Latitude lock
10. Polar axis
11. Latitude adjustment knob
12. Optical tube assembly
13. Optical tube saddle plate
14. Cradle rings
15. Cradle ring lock knobs
16. Viewfinder bracket mounting bolts
17. Focuser
18. Focuser thumbscrew
19. Eyepiece
20. Viewfinder bracket
21. Declination axis
22. R.A. lock
23. Dec. lock
24. 6 x 30 viewfinder
25. Telescope front dust cover
26. Viewfinder bracket thumbscrews
27. R.A. setting circle
28. Dec. setting circle
29. Latitude dial
30. Azimuth lock
31. Focus knobs
32. Polar shaft acorn cap nut
33. Azimuth base
34. Azimuth shaft bolt
35. R.A. worm block assembly
36. Dec. worm block assembly
37. Cradle ring attachment knobs
38. Tripod leg Phillips-head fastener screws
39. Tripod-to-mount attachment points
40. Accessory shelf
41. Accessory shelf central mounting knob
42. Tripod leg brace supports
43. Tripod leg lock knobs
Key to Fig. 1
