OM-867 Page 2
SECTION 3 – INSTALLATION
WARNING
ELECTRIC SHOCK can kill.
•
Do not touch live electrical parts.
•
Turn Off welding power source and disconnect input
power before inspecting or installing. Stop engine on
welding generator.
FUMES can be hazardous; LACK OF
F R E S H A I R A N D P R O P E R
VENTILATION can be harmful.
•
Do not breathe welding fumes.
•
Place unit only where there is a good fresh air supply
and proper ventilation.
swarn11.1* 3/93
3-1. Location
ST-084 121-A
Turn Off welding power source.
1 Meter
Place meter on bench, welding
power source, or other convenient
location.
Inches Millimeters
A 6 152
B 11-5/8 295
C 8-3/8 213
A
B
C
1
Figure 3-1. Overall Dimensions
