WARNING
Always replace a fuse with one of the
same rating. Otherwise you may
damage the electric system.
Replacing the fuses under the hood
If the headlights or other electrical
components don't work and the fuses in
the cabin are OK, inspect the fuse block
under the hood. If a fuse is blown, it must
be replaced. Follow these steps:
1. Turn off the ignition switch and all
other switches.
2. Remove the fuse block cover.
3. Pull the fuse straight out with the fuse
puller provided on the inside of the
engine compartment fuse block cover.
4. If a fuse is blown, replace it with a new
one of the same amperage rating.
Normal Blown
NOTE
To replace the MAIN fuse, contact an
Authorized Mazda Dealer (page 8-42).
Maintenance and Care
Owner Maintenance
8-41
