Users Manual & Installation Guide
PV- SERIES 4-P ORT RS232/RS422/RS485
Page 3 of 7
M
ODEL
S
ELECTION
PV - X X X X - H – S – 5V
Number of RS232 ports (0-4)
Number of RS485 ports, 2-wire (0-3)
Number of RS485 ports, 4-wire (0-1)
Number of RS422 ports (0-1)
0 = Standard, H = High-speed
0 = Non-stackthrough, S = Stackthrough
5V= do not require +/-12V
A
VAILABLE
M
ODELS
Model no. Description/Type
PV-0301 /-H/-S 3xRS485 (2-wire) + 1xRS422
PV-0310 /-H /-S 3xRS485 (2-wire) + 1xRS485 (4-wire)
PV-1201 /-H /-S 1xRS232 + 2xRS485 (2-wire) + 1xRS422
PV-1210 /-H /-S 1xRS232 + 2xRS485 (2-wire) + 1xRS485 (4-wire)
PV-2002 /-H /-S 2xRS232 + 2xRS422
PV-2011 /-H /-S 2xRS232 + 1xRS485 (4-wire) + 1xRS422
PV-2101 /-H /-S 2xRS232 + 1xRS485 (2-wire) + 1xRS422
PV-2110 /-H /-S 2xRS232 + 1xRS485 (2-wire) + 1xRS485 (4-wire)
PV-3001 /-H /-S 3xRS232 + 1xRS422
PV-3010 /-H /-S 3xRS232 + 1xRS485 (4-wire)
PV-4000 /-H /-S 4xRS232
Port
Model A B C D
0301 ⊗ ⊗ ⊗ #
0310 ⊗ ⊗ ⊗
1201 • ⊗ ⊗ #
1210 • ⊗ ⊗
2002 • • # #
2011 • • #
2101 • • ⊗
2110 • • ⊗
3001 • • • #
3010 • • •
4000 • • • •
• : RS232 ⊗ : RS485, 2-wire
# : RS422 : RS485, 4-wire
