Mega Catch Mini - Manual (Page 27)

27
Parts List
Reference
Number
Description Part Number
17 Firebox Panel Set with Insulation 50-1162
18 Side Louver 50-1163
19 Burn Pot 50-1166
20 Burn Pot Liner 50-1167
21 Burn Pot Bottom 50-1168
22 Front Louvers 50-1169
23 Lid Set 50-1171
24 Stove Top Assembly 50-1172
Hopper Guard 50-1174
25 Handle Bracket 50-1177
26 Draft Slider 50-1178
27 Door Assembly Complete 50-1179
28 Ash Pan Cover 50-1180
29 Ash Pan 50-1181
30 Ash Shelf Louver 50-1182
31 Cabinet Side Left 50-1183
32 Starter Pipe 3” 50-1185
33 60mm Tangential Blower Mini - 115V 50-1217
34 Mini Hearth Pad 50-1219
Mini Domestic Owners Manual 50-1220
Mini Domestic Technical Manual 50-1221
Painted Panel Kit for Flush Controls 50-1234
Burner Scraper Tool (Option) 50-1254
Mini Stainless Steel Panel Kit (Option) 50-1257
35 Circuit Board Control Panel Flush 50-1270
36 Cabinet Side Right for Flush Controls 50-1271
37 Leveling Legs (Set of 4) 50-1296
38 Back Grill 50-1297
