GIGABYTE Network Device GA-7N400 - Manual (Page 26)

Overview
The SATARaid GUI offers the user the ability to easily monitor your RAID Set.
To launch the GUI, simply double-click on the icon located in the bottom right hand corner of the
Desktop. If the icon does not appear in the bottom right hand corner of the desktop, find where the appli-
cation was saved and launch from there.
Upon launching the GUI, the the first window which identifies the computer running SATARaid should
appear similar to the following:
5. USING SILICON IMAGE SATARaid GUI
Save configuration to a file button
The Events tab reports
logged events.
Configuration
Tree
Copy configuration to clip board
Send configuration by e-mail
Help on SATARaid
About SATARaid
* For PCI-3112 or 3512
*
SATA RAID Function 23
