GE ZEK737BWBB - Manual

Revised 7/97
Monogram. ™
UL
R
Listed by
Underwriters
Laboratories
ZEK737BWBB—Single Convection Oven
Dimensions and Specifications (in inches)
Cutout Dimensions:
H 27-1/2" min. (699 mm)
W 25" min. (635 mm)
D 23-5/8" (600 mm)
cabinet depth required from front frame to inside rear
cabinet wall.
Monogram built-in double ovens require a separate,
properly grounded 3-wire 120/208 or 120/240 volt,
60 Hz power supply, protected by a time delay fuse or
circuit breaker. Ovens are supplied with a flexible
power cable, which must be attached to a junction
box. The cable length for convection type ovens is 54".
Double ovens are rated 6.8 KW at 240 volt, and
5.1 KW at 208 volt.
Single ovens are rated 3.4 KW at 240 volt, and 2.6 KW
at 208 volt.
Installation Information:
Before installing, consult installation instructions,
Pub. No. 49-8804, packed with the product for current
dimensional data and for alternate installation
options.
26-13/16"
(681 mm)
28-9/16"
(725 mm)
25" min.
(635 mm)
27"
(686 mm)
32-1/2"*
(826 mm)
24-7/16"
(621 mm)
10"
Locate electrical outlet within 10" of left side of
opening 34" above cutout floor or 5" below cutout floor.
* recommended
27-1/2"
(699 mm)
min.
23-1/2"
(597 mm)
23-5/8"
(1600 mm)
For answers to your GE Monogram, ™ GE Profile, ™
GE, Hotpoint and RCA appliance questions, call
GE Answer Center
® service, 800.626.2000.
