Giant GXR - Manual (Page 5)

ITEM# Part# Description QTY.
1 07805 Radial Shaft Seal 1
2 06310* Adapting Flange 1
3 06294 O-Ring 1
4 06300 Rear Bearing 1
5 06690** Wobble Plate 6.1 Degree 3/4"
(GXRH1114) 1
5 06566** Wobble Plate 6.3 Degree 3/4"
(GXRH2424) 1
5 06696 + Wobble Plate 6.1 Degree 7/8"
(GXRV2224) 1
5 06322 + Wobble Plate 6.3 Degree 7/8"
(GXRV2424) 1
5A 07882 Shaft Ring 1
6 06301 Front Bearing 1
7 06289 Spring Disk 3
8 06287 Plunger, 16mm 3
9 06288 Plunger Spring 3
10 06299 Socket Bolt 6
11 08192 Gasket 1
12 06273 Oil Drain Plug 1
13 06282 Crankcase (GXRV) 1
13 06338 Crankcase (GXRH) 1
14 08083 Vent Cap (Horizontal Only) 1
15 06316 Oil Seal 3
17 06292 Spacer 3
18 07374 Valve Spring 6
19 06267 Guided P-Valve 3
20 06290 Pressure Ring 3
21 06315 V-Sleeve, 16mm 3
22 06296 Discharge Plug 3
GXR SERIES PARTS LIST
ITEM# Part# Description QTY.
23 12007 O-Ring 3
24 23507 O-Ring 1
25 06710 Seat 1
26 06386 6mm S.S. Ball 1
27 06385 O-Ring 1
28 06384 Plastic Poppet Valve 1
29 06382 Spring 1
30 06410 O-Ring 1
31 06392 Cap 1
35 06412 Manifold 1
36 06295 Discharge Valve Cone 3
38 07910A Triangle O-Ring 1
39 06298 Suction Flange 1
40 06302 Stud Bolt 4
44 A 06308 Orifice, 1.8mm 1
44 A 06339 Orifice, 2.1mm 1
44 A 06340 Orifice, 2.3mm 1
45 06312 O-Ring in Nozzle 1
46 07913 O-Ring 1
47 06303 Injector Retainer 1
48 23009 Spring 1
49 23010-0100 Ball 1
50 12516-0001 O-Ring 1
51 12517 Hose Barb 1
53 23422A Thermal Relief Valve 1
54 ++ 07468 Locktooth Washer 4
55 ++ 07467 Screws 4
56 ++ 06334 Mounting Flange "X" Style 1
Position Item# Description Torque Amount (ft.-lbs)
10 06299 Socket Bolt 100 in.-lbs.
40 06302 Stud Bolt 150 in.-lbs.
GXR SERIES TORQUE SPECIFICATIONS
* When ordering 06310, please order 17026, which includes 06300, 07805, and 06294.
** When ordering 06566, please order 17047 which includes 06566, 06301, and 07882.
** When ordering 06690, please order 17052 which includes 06690, 06301, and 07882.
+ When ordering 06322, please order 17027 which includes 06322, 06301, and 07882.
+ When ordering 06691, please order 17053 which includes 06691, 06301, and 07882.
++ 09103 Gasoline Flange Kit
A = See pump numbering system page 7
