Model H6310 Jump Starter/Compressor

-7

-

Jump Starter

When jump starting any automobile,
always check the actual symbols on the
battery to ensure which terminals are posi-
tive "+" or negative "-". (DO NOT rely on
red or black colors of the cables already
connected to the battery, as these are not
always consistent.) Also, never touch the
red and black terminal clamps together
as this will short out the jump starter and
may cause fire, explosion, or damage to
equipment.

To use the jump starter:

1. Remove the black and red terminal

clamps from the holders.

2. Clip the black terminal clamp on the

negative "-" battery terminal.

3. Clip the red terminal clamp on the posi-

tive "+" battery terminal.

4. Turn the main power switch ON.

5. Start the car.

— If car starts, remove the red terminal

clamp first, then the black.

— If car won't start, refer to

Troubleshooting on

page 9.

Tire Inflater

The air nozzle is tucked inside the stor-
age compartment that is located near the
black terminal clamp. If you are filling a
tire at night, and you are on the side of the
road near oncoming traffic, use the hazard
lights to increase your personal safety.

To use the tire inflater:

1. Remove the cover to the storage com-

partment, and pull out the air hose.

2. Clamp the air hose to the tire valve

stem.

3. Turn the main power switch ON.

4. Push the air pump button to "–" to start

the air pump.

5. Fill the tire while monitoring the PSI

gauge, and stop the air pump (push
button to "O") when the tire is filled to
the correct PSI listed on the tire.

OPERATIONS

Touching red and black terminal

clamps together will cause a short

and may cause an explosion or fire.

Never touch red and black terminal

clamps together!
