Graco 6500 - Manual (Page 10)

9 762-3-00 10
To Fold Stroller
Before folding, fold canopy.
Step 1.
Fully recline the seat back.
Step 2.
Pull latches up to release and
fold handle down.
OR
On certain models, pull red
latches on handle up to release.
Fold handle down.
Step 3.
Close and lock storage latch.
To Use Arm Bars*
Curved side of
bracket UP
“Left” and “right” arm bars are as caregiver would see them
from front of stroller.
Step 1.
Snap arm bars onto sides of front legs as shown below.
The brackets must be attached with curved side up.
Step 2.
To close the arm bars, face the stroller. Push the free end
of the left arm bar into the upper hole in the center mount
of the stroller. Push the free end of the right arm bar into
the lower hole of the center mount. CHECK that arm bars
are secure by pulling on them.
Step 3.
To open arm bars, squeeze the metal buttons near the
free end of each arm bar to unlock them. Buttons may
be hidden under the arm bar pad.
Always secure your child with the seat
belt. The arm bars are not restraint devices.
DO NOT lift the stroller by the arm bars.
Use care when clamping the arm bars on the stroller
with a child in the stroller.
Right arm bar
Left arm bar
Buttons
To Change to Swivel or
Non-swivel Wheels*
Front swivel wheels lock for use on uneven surfaces such
as grass, stones or gravel.
Before locking swivels, first push stroller forward a few feet
to ensure the wheels are correctly positioned.
Push buttons up or down, depending on model, to lock or
release swivels. Turn swivel to check that it is locked or
released.
To Adjust Seat Backs*
Step 1.
To recline the seat, push the two
latches behind the seat toward
each other.
Step 2.
To adjust seat to upright
position, lift the seat back until
both recline latches are locked.
Fabric caught in
the latches may prevent them
from locking. When returning
seat to upright position, do not
allow fabric to be pinched in
the latches.
11
HELPFUL HINTS
IF WHEEL SQUEAKS, use a light oil
(e.g., WD-40, 3-in-1, or sewing machine
oil). It is important to get the oil into the
axle and wheel assembly as illustrated.
WHEN USING YOUR STROLLER AT THE BEACH,
completely clean your stroller afterward to remove sand
and salt from mechanisms and wheel assemblies.
TO STAND FOLDED STROLLER, lock the brakes.
CARE AND MAINTENANCE
TO CLEAN THE SEATS on models
with side latches, unscrew the
plastic clasps under the seats
and the two release latches on
the handle. (When removing
latches, note location of the long
screw and the wire attachment
holes.) Hand wash in warm water
with a mild detergent. Drip dry
only—seats contain plastic inserts.
Replace seats on frame when dry.
Reattach wires to latches, then
screw latches and clasps back
onto stroller frame.
REMOVABLE SEAT PADS (if so equipped) may be
machine washed in lukewarm water on delicate cycle
and drip-dried. NO BLEACH.
FROM TIME TO TIME CHECK YOUR STROLLER
for loose screws, worn parts, torn material or stitching.
Replace or repair the parts as needed. Use only Graco ®
replacement parts.
TO CLEAN STROLLER FRAME, use only household
soap or detergent and warm water. NO BLEACH.
EXCESSIVE EXPOSURE TO SUN OR HEAT could
cause fading or warping of parts.
Return the form below with payment to:
GRACO CHILDREN’S PRODUCTS INC.
CUSTOMER SERVICE DEPARTMENT
P.O. BOX 100, MAIN STREET
ELVERSON, PA 19520
SHIP TO:
Name
Address
City, State, Zip
( )
Telephone
Check enclosed
(payable to Graco Children’s
Products Inc.)
Charge to credit card:
Visa
MasterCard
Discover
Account #:
Expiration date:
Signature:
Seat
Canopy
Front swivel assembly
Rear axle
Rear axle mounts
Rear wheel
Basket
Right arm bar
Left arm bar
Removable cloth
pad
Replacement Parts
Instructions for ordering stroller parts:
Complete form below. Your stroller model number MUST
be included on the form to ensure proper replacement
parts. Your model number can be found on a sticker
on the rear leg of your stroller. Payment must
accompany your order.
Subtotal:
Shipping
& handling*: $5.00
6% sales tax
(PA only):
Total:
*$15.00 outside the continental U.S.
IF YOU NEED HELP
If you have any questions or if you need
any part not listed, please call toll-free:
1-800-345-4109
or visit our Internet website, www.gracobaby.com.
Parts List:
Seat ...........................................
Canopy ......................................
Front wheel assembly ...............
(2 wheels per unit)
Rear axle ...................................
Rear axle mounts ......................
Rear wheel ................................
Rear wheel hardware ................
Basket .......................................
Right arm bar* (seen from front)
Left arm bar* (seen from front)
Removable cloth pad* ...............
* On certain models only.
Price:**
$20.00
$18.00
$16.00
$10.00
$ 5.00 (for two)
$ 8.00 (each)
No charge
$16.00
$13.00
$13.00
$16.00
** Prices subject to change
* without notice.
12
*
On certain models
The following optional features are found only
on certain models:
Model No.
(required)
Serial No.
(required)
