Using the Tray
Step 1.
Unlatch the tray by squeezing
the two latches under the tray
at the same time, and lift up.
Be careful not to let the tray
hit your baby when lifting or
closing the tray.
Step 2.
To latch tray, push it down
firmly.
If tray does not latch, check back brace to be sure the word
“REAR” is away from the seat.
Step 3.
Push the elastic loop through
the hole on one side of seat.
Step 4.
Fold cover around bottom of
seat. Then fasten the hook into
the elastic loop on one side as
shown. Repeat on other side.
CAUTION: Be sure the seat
cover at armrest does not
interfere with tray latching.
Attaching the Seat Belt
Reclining Back—
Four Positions
Pull adjustment wire upward
and pull seat backward to
recline seat. Extra pressure is
required to go from the third
position to full recline.
For upright position, simply lift
back of seat forward.
Tray must be latched at all times when
baby is in swing. Pull up on tray to be sure it is latched.
Step 4.
To start swing, push the desired
speed button and give the
swing a gentle push.
•
Push “1” for the lowest ride.
•
Push “2” for medium ride.
•
Push “3” for the highest ride.
Step 5.
To turn swing off:
On models without music, push
the OFF button.
OR
On models with music, push
the active speed button.
Indicator light will go off and
swing will stop.
Attaching the Seat Cover
Step 1.
With baby out of swing, open
the battery compartment lid by
inserting a coin (penny, nickel
or dime) into the coin slot. After
the lid pops open, swing it
down and remove it.
Step 2.
Insert four “D” cells. CHECK
that the batteries are put in
correctly. Your swing will not
run if the batteries are put in
backwards.
Step 3.
To replace lid, put the two
tabs of the lid into the two
slots in the bottom of the motor
housing. Swing lid up, and
press it into place until you
hear the latch click.
Coin
slot
Installing the Batteries
To Use Head Supports
(on certain models)
Back of cloth seat pad
To provide head support for a
smaller child, insert the two head
support pads into the pockets
located in the back of the cloth
seat pad.
Step 1.
Thread one end of the seat
belt through the belt retainer
as shown.
Step 2.
Thread both ends of seat belt
through the buckles as shown.
CHECK that the belt is threaded
correctly by pulling on the seat
belt. The belt should not slip
through the buckle.
To release, push in on front of
buckle.
Step 1.
Slide the pocket of the seat
cover over the top of the seat
as shown.
Step 2.
Pull the crotch strap and both
ends of the seat belt through
the slots in the seat cover.
Starting the Swing
Step 2.
Place crotch strap between
child’s legs and snap both
side buckles to the center
buckle. Adjust belt as needed
to get a snug fit around your
child.
Step 3.
Close the tray. CHECK that
the tray is latched by pulling
up on the tray.
Do not
depend on the tray or seat
belt alone to hold your baby.
Always secure your baby
with both the seat belt and
tray when your baby is in
the swing.
CHECK that all parts are securely fastened together
before using the swing.
Step 1.
Open tray and seat belt. Place baby in the seat.
(If your child is very small, you may want to use
rolled-up blankets as a prop.)
Observe the swinging motion for a minute. It takes time
for the swing to adjust to a setting. Change setting as
needed.
A small, quiet baby will swing higher on each setting
than a larger, more active baby.
Toy Mounting System
Your swing has a toy mounting system in the tray. This
swing model does not come equipped with toys. If you
would like to order toys, please see the enclosed leaflet
for information. Please insert the two plastic covers as
described below to fill the holes in the tray.
To Install Covers
To insert a cover into the tray of your
swing, first push one side into a notch,
then push in the other side.
