Specifications
Frequency Response:
16Hz to 36kHz, +/- 1dB
Sensitivity:
91 dB 1 watt 1 meter
Controls (on amplifier):
Gain, Phase,
low-pass,
high-pass
Controls (on speaker):
Rear Tweeters (+/- 1 dB)
Midrange (+/- 0.75 dB)
Input Impedance:
4 ohms (nominal)
33K
ohms
(amplifier)
HF Transducers (per side):
26 Genesis 1” Circular Ribbon
Tweeters (20 front, 6 rear)
Midrange Transducer (per side): Single 75” Ribbon
LF Transducers (per side):
Six Genesis 12” woofers with
ribbed aluminum cones
Amplifier Power Rating:
Six channels per side
@400 watts each
Amplifier
Inputs:
1pair
XLR
(balanced)
1pair
RCA
(single
ended)
Dimensions:
Mid/Tweeter Wing:
H 90” x W 41.5” x D 5” each
Woofer Tower:
H 90” x W 15.5” x D 19” each
Amplifier:
H 10” x W 12” x D19” each
Crossover:
H 3” x W 6” x D 8” each
Weight:
1,250
lbs
(568kg)
per
side
70 lbs (32kg) amplifier per side
Finish:
Rosewood/Corian
