-74-
Model G9901/G9902/G9903 Milling Machine
Model G9903 Upper Drive System Breakdown
REF PART # DESCRIPTION REF PART # DESCRIPTION
701 PSB01M CAP SCREW M6-1 X 16 740 P9903740 UPPER PULLEY HALF
702 P9903702 BEARING CAP 741 PSS01M SET SCREW M6-1 X 10
704 P6007 BALL BEARING 6007ZZ 743 P9903743 LOWER PULLEY HALF
706 P9903706 CAP SCREW M8-1.25 X 150 744 P9903744 COMPRESSION SPRING
707 PN02M HEX NUT M10-1.5 745 P9903745 SPRING COLLAR
708 P9903708 MOTOR 2HP, 220V,3-PH 746 PSB38M CAP SCREW M5-.8 X 25
708-1 P9903708-1 MOTOR MOUNT PLATE 748 PSB14M CAP SCREW M8-1.25 X 20
708-2 P9903708-2 MOTOR WIRING JUNCTION BOX 752 P9903752 TAPER PIN 8 X 30
708-3 P9903708-3 MOTOR FAN COVER 753 P9903753 MIDDLE HOUSING
708-4 P9903708-4 MOTOR FAN 754 P9903754 LOWER COVER
709 PB32M HEX BOLT M10-1.5 X 25 756 P9903756 RIVET C2 X 5
710 P9903710 UPPER HOUSING 758 P9903758 NAMEPLATE
711 P9903711 SHAFT 761 P9903761 NAMEPLATE
712 PRP56M ROLL PIN 4 X 25 763 P9903763 LOWER HOUSING
713 P9903713 CLAMPING PLATE 764 PS19M PHLP HD SCR M5-.8 X 6
714 P9903714 DRAWBAR 765 P9903765 COVER PLATE
715 PRP42M ROLL PIN 3 X 20 766 P9903766 RETAINING RING 6MM
716 P9903716 SHAFT 767 P9903767 BRAKE OPERATING FINGER
717 PS52M PHLP HD SCR M4-.7 X 20 768 P9903768 SHAFT
718 PW05M FLAT WASHER 4MM 769 P9903769 HANDLE KNOB
722 P9903722 BEARING SLIDING HOUSING 770 P9903770 HANDLE
723 P9903723 BALL BEARING 6010-2RS 771 P9903771 PIN
725 P9903725 PULLEY 772 PSS26M SET SCREW M5-.8 X 6
726 P9903726 RETAINING RING 38MM 773 P9903773 SHAFT
727 P9903727 VARIABLE SPEED BELT 775 P9903775 BRACKET
728 P9903728 PULLEY 777 PSS01M SET SCREW M6-1 X 10
729 P9903729 BEARING CAP 778 PSB02M CAP SCREW M6-1 X 20
730 P9901723 BALL BEARING 6010-2RS 780 PS08M PHLP HD SCR M5-.8 X 12
731 P9903731 BRAKE SPRING 783 P9903783 REGULATING RING
732 P9903732 BRAKE SHOE 785 P9903785 MOTOR SPLINE SLEEVE
734 P9903734 UPPER COUPLING SHAFT 786 P9903786 KEY 6 X 6 X 70
735 PSS01M SET SCREW M6-1 X 10 793 P9903793 SPLINE SLEEVE
738 PK149M KEY 8 X 8 X 25
